Auto Release Adjustable Square Tube Superlock Panels
J&D Manufacturing’s popular Square Tube Superlock Panel is now fully adjustable! Neck openings have three adjustment levels to give an additional 1¼” opening. J&D’s full line of square tube mounting brackets offer endless combinations to flush mount, face mount, or comfort tilt mount your headlock panels. New and improved features include a hideaway control rod handle and an easy release latch to keep your fingers clear during individual release.
Features:
- Standard panels available in cow or heifer models
- 2" x 2" square tubing on top and bottom rails
- Panels are hot dip galvanized INSIDE and OUT after welding
- 7 1/2", 8 1/8", and 8 3/4" adjustable neck opening on cow panels 6 1/4", 6 7/8", and 7 1/2" adjustable neck opening on heifer panels
- 2 1/2" spacing between openings on cow panels 19" spacing between openings on heifer panels
- 2" x 2" square tubing on top and bottom rails
- Panels are hot dip galvanized INSIDE and OUT after welding
- Easy release safety latch with no loops or eyeholes to catch your finger in
- Hideaway control handle folds down flat to panel
- 40" high standard panel height
- Wide 17" to 18 1/2" head entry opening for easy access (head opening size changes when neck opening is adjusted)
- Lock in one or more animals and release the rest
- Swing arm is counterweighted to automatically return to the open position
- Overswing allows quick and safe release of a downed cow
- Rubber cushion on swing arm return to reduce noise
- No latch movement in open position
- Operate up to 200' of headlocks with a single control rod handle
